| General | |||
| Keyboard Key panel | Electromechanical | ||
| Joystick | 3-axis, vector-solving, with twisting, return to-center head | ||
| Keyboard Connector | RJ-45, RS232, RS485, RS422, USB | RS232, RS485, RS422 | RS485, RS422 |
| Keyboard Communication | Direct Mode, Network Mode | Direct Mode | Direct Mode |
| Direct Mode | Interface: RS232/RS485
DVR Protocol: DH2 Dome Protocol: DH-SD/PELCO-D/PELCO-P/PELCO-D1/PELCO-P, etc |
||
| Network Mode | Interface: RJ45
DVR/Network Dome: IP Address/Port/Protocol |
N/A | N/A |
| Display | LCD, 75.2mm×33.85mm | ||
| Environmental | |||
| Power Supply | Power adapter, input 100V~240V 50Hz/60Hz, output DC12V/1000mA | ||
| Power Consumption | 5W | ||
| Working Temperature | -10℃~+55℃ |
| Working Humidity | 10% ~ 90% |
| Atmosphere Pressure | 86kpa~106kpa |
| Dimension | 330mm×160(140)mm×37.5(21)mm (W×D×H)(height: 100mm including joystick) |
| Weight | 2.5kg (Including package) |
